1 pair of carbon folding paddles fits Hobbywing X8/X8plus/X9/X9Max/X11 power systems

PHY3090-CF——X8
Hole pitch: 31MM hole pitch, 6MM middle hole, 3MM side hole
Installation screw size: 3 * 10
Lock screw: 6 * 22
Lock screw diameter: 6MM
Inner diameter of washer: 6MM
Outer diameter of washer: 15.7MM
Thickness of washer: 0.7MM
Aperture distance: 70MM

3090 Carbon Fiber Folding Award
Suitable for Haoying X8 power
Blade length: 36CM Weight of a single blade: 44.6g Blade width: 58CM Bore diameter: 6MM
Root height: 7.5MM

PHY34711-CF——X9
Hole pitch: 32MM hole pitch, 10mm middle hole, 4mm side hole
Installation screw size: 4 * 16
Lock screw: 5 * 20, column diameter: 10mm
Inner diameter of gasket: 101MM Outer diameter of gasket: 21MM Thickness of gasket: 0.6MM Aperture distance: 70MM

34711 Carbon Fiber Folding Award
Suitable for Hobbywing X9 power
Blade length: 42.5CM
Weight of single blade: 80g
The widest part of the blade: 9CM
Paddle hole inner diameter: 10mm
Blade root height: 7.7MM

PHY36190-CF——X9PLUS/MAx Power System Upgrade -36190 Carbon Fiber Duplex Folding Award
Adopting M-YB new aviation materials, with uniform density, light weight, high strength, no small holes or pulling materials in appearance, and very small weight difference between individual pieces
The carbon fiber material is made of imported Mitsubishi material, which is resistant to impact and impact, suitable for sowing and fertilizing, and suitable for high wind and high-altitude high temperature application scenarios.
Each product is tested for dynamic balance before leaving the factory, and can be replaced at will. Flexible blade adjustment is available, supporting one blade adjustment
Blade length: 44CM
Single leaf weight: 69g
Paddle hole inner diameter: 6MM/8MM/10MM
Blade root height: 10mm
The widest part of the blade: 8C

PHY41135-CF——X11:
Hole spacing: 31mm, middle hole 14mm, side hole 4mm, installation screw size: 4 * 16
Screw for locking the propeller: 6 * 16
Lock award steel column diameter: 10mm, gasket inner diameter: 10mm, gasket outer diameter: 32mm, gasket thickness: 2mm, aperture distance: 80mm, purpose: suitable for "Good fit X11"

X11 powertrain upgrade -41135 carbon fiber core folding award
Using M-YB new aviation materials, with uniform density, light weight, high strength, no small holes in the appearance, no pulling material, and very small weight difference between individual pieces.
The carbon fiber material is made of imported Mitsubishi material, which is resistant to impact and impact, suitable for sowing and fertilizing, and suitable for high wind and high-altitude high temperature application scenarios.
Each product is tested for dynamic balance before leaving the factory, and the paddles can be replaced at will. The paddles can be flexibly adjusted and support one blade adjustment.
Blade length: 49CM
Single leaf weight: 93g
Inner diameter of blade hole: CCW: 11MM
CW: 10mm
Blade root height: 13.5MM
The widest part of the blade: 9.8CM
