Description
Using C8051F850 MCU, pipelined 8 bit C805 core.
FlyDragon Lite series ,small size and light weight.
Unique circuit design, strong anti-interference.
Start mode can be set, throttle response is fast and speed control is linear smooth.
Low-voltage protection threshold value can be set.
Multiple protection features: Abnormal startup protection, over-heat protection, throttle signal loss protection, low-voltage cut-off protection, etc.
High power safety performance : wherever the throttle lever is, the motor will not start immediately.
Judge the working condition via alarm.
Users can set functions as their demand, Cycle programming menu which easy to operate.
Built-in BEC, high output power, less power loss.
|
Model |
Con.Current |
Burst Current |
BEC |
LiPo |
Size (mm) |
Weight |
|
20A |
20A |
30A |
5V/2A |
2-4S |
49x25.5x10.5 |
23g |
|
30A |
30A |
40A |
5V/2A |
2-4S |
49x25.5x10.5 |
25g |
|
40A |
40A |
50A |
5V/3A |
2-4S |
65x26x15.5 |
51g |
|
50A |
50A |
60A |
5V/3A |
2-4S |
65x26x15.5 |
46.5g |
