- Mounting Size: L1=40mm L2=33.5mm W=20mm D1=3mm
- Note: There is 1-2mm slight error for the manual measurement.
- Outside Diameter: 1.6mm/ 60core (tinning wire/ core wire)
- Wire Outside Diameter: 0.08mm (#22AWG wire)
- 22# silicone wire, gold-plating plug
- Switch: 2A/250V AC, max 20A DC for 10min Available
- Very light (23g), can be used for small to large airplane
- One Switch: either for connecting and disconnecting the receiver circuit, either for connecting and disconnecting the CDI circuit.
- One plug compatible with JR and FUTABA: either for connecting with the receiver battery, either for connecting with the CDI battery to supply power without opening the canopy.
- 1* switch
