40G Digital Standard Waterproof Metal Gear Servo 4.8-6.0V 55*20.3*46mm for RC Airplane Car Model Robot Smart Device

Specification

◎Size: 55 * 20.3 * 46 MM

◎Maximum torque: (4.8V) 12.0 KGF.CM/(6.0V) 15.0 KGF.CM

◎No-load speed: (4.8V) 0.25 SEC/60 °/(6.0V) 0.22 SEC/60 °

◎No-load current: (4.8V) 80 MA/(6.0V) 100 MA
Load life: (4.8V) 220000 CYCLES/(6.0V) 210000 CYCLES

◎Operating environment: - 20 °~60 °

◎Wiring polarity:
Orange (signal line); Red (positive); Coffee (negative)

◎Applicable to aircraft model/vehicle model/manipulator/educational robot/smart home, etc
