BLS6221CHV 21.6kg.cm Digital Steel Metal Gears HV Brushless Standard Servo For RC Models

$32.23 $0.00 ( / )
Feature: -- High performance programmable digital high voltage standard servo -- High-precision Taiwan-made aluminium gears with hard anodizing -- High quality brushless motor -- Middle CNC aluminium case -- Dual ball bearings -- Waterproof Specification: Dead band: 2μs default Working frequence: 1520μs / 330hz Operating Voltage: DC6.0~7.4 V| Operating Speed...
Add to Wishlist
Categories:
Feature:
-- High performance programmable digital high voltage standard servo
-- High-precision Taiwan-made aluminium gears with hard anodizing
-- High quality brushless motor
-- Middle CNC aluminium case
-- Dual ball bearings
-- Waterproof



Specification:
Dead band: 2μs default
Working frequence: 1520μs / 330hz
Operating Voltage: DC6.0~7.4 V|
Operating Speed (6.0V): 0.10sec/60 degrees
Operating Speed (7.4V): 0.08sec/60 degrees
Stall Torque (6.0V): 17.5 kg.cm (243.08oz/in)
Stall Torque (7.4V): 21.6 kg.cm (300.02oz/in)
Dimensions: 40.2X20X41mm /1.58X0.79X1.61 in
Weight: 62g (2.19oz)
Connector Wire Length: JR320 mm (12.6in)



 Packet included:   1 piece BLS6221CHV servo
Vendor:

KingMax

SKU:

KMBLS6221CHV

Weight:

0.113 kg
