Corona CS-928BB 9g/ 2.0kg.cm/ 0.13sec Plastic Gear Micro Servo RC Aircraft accessories

$2.82 $0.00 ( / )
9g/ 2.0kg.cm/ 0.13sec Servo CS-928BB Plastic Gear Micro Specification   Item NO CS928BB Size 22.5X11.5X24.6mm(0.88"x0.45"x0.96") Weight  9g Operating Voltage 4.8V / 6.0V Operating Current 200mA / 240mA Operating Speed 0.14sec.60º/ 0.13sec.60º Stall Torque 1.8kg.cm / 2.0kg.cm Dead Band ââ€?/span>5uSec Operating Travel 40º/one side pulse traveling 400us Potentiometer 2 slider/Direct Drive Ball bearing  MR85 Gear  Plastic   Connector wire  215mm Operating Temperature Range -20℃~+60ââ€?/span>
Add to Wishlist
Categories:

9g/ 2.0kg.cm/ 0.13sec Servo CS-928BB Plastic Gear Micro

Specification



Item NO CS928BB
Size 22.5X11.5X24.6mm(0.88"x0.45"x0.96")
Weight  9g
Operating Voltage 4.8V / 6.0V
Operating Current 200mA / 240mA
Operating Speed 0.14sec.60º/ 0.13sec.60º
Stall Torque 1.8kg.cm / 2.0kg.cm
Dead Band ââ€?/span>5uSec
Operating Travel 40º/one side pulse traveling 400us
Potentiometer 2 slider/Direct Drive
Ball bearing  MR85
Gear  Plastic
  Connector wire  215mm
Operating Temperature Range -20℃~+60ââ€?/span>
Vendor:

Corona

SKU:

CS928BB

Weight:

0.02 kg
