EME Auto Starter for DLE55/DA50/DA60/EME55-II/EME60 Gasoline Engine

$114.86 $0.00 ( / )
Net Weight: 540g Working Voltage: 3-15V (12V for the best ) Motor Length: 57mm Motor Diameter: 37.5mm Shaft Length: 9mm Shaft Diameter: 3.17mm Recommended ESC: 60A (need to buy separately) Recommended Electric Switch: (Item No.: EME-S-12) (need to buy separately. Please look at this listing if you need. https://www.ebay.com/itm/252360752547) Application:...
Add to Wishlist
Categories:
  • Net Weight: 540g
  • Working Voltage: 3-15V (12V for the best )
  • Motor Length: 57mm
  • Motor Diameter: 37.5mm
  • Shaft Length: 9mm
  • Shaft Diameter: 3.17mm
  • Recommended ESC: 60A (need to buy separately)
  • Recommended Electric Switch: (Item No.: EME-S-12) (need to buy separately. Please look at this listing if you need. https://www.ebay.com/itm/252360752547)
  • Application: suitable for DLE55, EME55, EME55-II, EME60 engines
Features
  • Two Long Installation Screws for mounting EME55, EME55-II, EME60 engines
  • Two Short Installation Screws for mounting DLE55, DA50, DA60, EME55-II engines
  • The starter also can be used for DLA56, DA50, DA60 engine after a bit refitting by users, those users who are well in refitting can have a try.
  • The starter is equipped with single bearing, so power only transfers from the motor to engine. But after the engine started, the power would not pass to motor, so as to protect the motor.
  • Equipped with high speed 550A carbon brush motor and cooling fan.
  • Coming with protection equipment, when the voltage and current exceed the specified value, the electric starter will automatically open and close² Acting as a brushed ESC and using radio controller to control the electric starter, so users no need to purchase another ESC.
  • Kindly Remark: When mounting and testing the starter, teeth of gear must be clenched properly and solid oil lubrication should be coated on the surface, otherwise the gear will be abraded soon.

Package include

  • 1* Electric Starter
Type:

Starter related

Vendor:

EME

SKU:

EME55ES

Weight:

0.85 kg
